Borgeson 800127 (Large Sector) Quick Ratio Steering Box Technical Information

BORGESON

FEBO Vendor
FEBO Vendor
Joined
Dec 12, 2019
Messages
11
Reaction score
5
Location
South Carolina
Borgeson Mopar 800127 technical information.

Steering Ratio: 14:1 (3.5 Turns Lock-to-Lock).

Input Shaft: 11/16"(17MM)-36 Spline.

Pitman Shaft: 1-1/4" Mopar with 32 Splines and 4 Master Splines, 7/8"-14 Thread.

Pressure Port: 16mm X 1.5 Flare (Located Closest to Engine).

Return Port: 16mm X 1.5 Flare (Located Closest to Input shaft).

Maximum Pressure: 1450 PSI Maximum Operating Pressure, 1100-1250 Optimal.

Flow Rate: 2.0-2.5 GPM Flow Rate Recommended.

Degrees of Rotation: +/-45.5 Each Direction of Center.

Maximum Front End Weight: 2,645 Pounds

Maximum Output Torque: 633 Ft. Lbs.

Operating Temperature Range: -40F to 248F (Big Block Applications Will Require a Cooler).

Weight: 26.46 Pounds.

MSRP: $629.00

Installation Drawing: http://borgeson.com/imageCD/800126_800127_Drawing.pdf



redlinegw

Member
Joined
Jul 29, 2011
Messages
18
Reaction score
4
Thanks! Pretty sure you got one of the first ones!
Yes, I think so and it will be the first upgrade for all my Mopars! Going to need one soon for my son's 68 Coronet he just bought! Talking with Bob Mehlhoff now about doing a father son install tech article for Mopar Muscle with some Hotchkis goodies as well.



BORGESON

FEBO Vendor
FEBO Vendor
Joined
Dec 12, 2019
Messages
11
Reaction score
5
Location
South Carolina
Yes, I think so and it will be the first upgrade for all my Mopars! Going to need one soon for my son's 68 Coronet he just bought! Talking with Bob Mehlhoff now about doing a father son install tech article for Mopar Muscle with some Hotchkis goodies as well.

View attachment 66750
Sweet! Hit me up if we can help out with it.
